Groove terminal type (slot width: 3 mm)
? Photoelectric IC output (switches ON when light is blocked, EE-SX398; switches ON when light is received, EE-SX498)
2 types)
? The applicable supply voltage is DC 4.5¨C17 V.
? Can be directly connected to C- MOS
OMRON EE-SX498: Series
OMRON EE-SX498 series: miniature photoelectric sensor (transparent) – EE-SX498
$2.50
Miniature photoelectric sensor (transmission type ¡¤ groove terminal type),Detection method: transmission type (Groove type),Connection method: terminal for printed circuit board,Detection distance: 3mm (groove width),Aperture Size: light emitting side/light receiving side same as 2 ¡Á 0.5mm,Output form: photoic,Power supply voltage: DC4.5 ~ 16V,Typical current consumption: 3.2mA,Response frequency: 3kHz,Maximum spectral sensitivity wavelength: 870nm,Peak wavelength of light emission: 940nm,Can be directly connected to C- MOS,Shell material: Polycarbonate,Action mode: ON when entering light
Availability: 88888888 in stock
